The Night Sky November 2006

Compiled by Ian Morison

This page, updated monthly, will let you know some of the things that you can look out for in the night sky. It lists the phases of the Moon, where you will see the naked-eye planets and describes some of the prominent constellations in the night sky during the month.

Image of the Month

Mk I

Saturn Occults the Sun
Image: Cassini Imaging Team, SSL,JPL,ESA,NASA.

Saturn

This is a totally unique view of Saturn seen from the night side. Light reflected from the rings illuminates the back of Saturn. The utermost broad ring - the E ring - is created by the newly discovered ice fountains on Enceladus. On the left, above the main rings is the blue dot of the Earth!

The Moon

Third Quarter Moon old Moon
Third Quarter Moon - by Ian Morison using a 6" Maksutov-newtonian and Canon G6 camera.
new first quarter full moon last quarter
Nov 20th Nov 28th Nov 5th Nov 12th

Some Lunar Images by Ian Morison, Jodrell Bank Observatory: Lunar Images

Highlights of the Month

Nov 17th,18th and 19th - The Leonid Meteor Shower - with a possible peak in activity on the morning of the 19th

Leonid meteor
A Leonid crossing the Sword of Orion

Every year, on November 17th and 18th, the Earth passed close to the trails of cometry debris from Comet Temple-Tuttle which produce the annual Leonid Meteor shower. The wonderful image above shows one of the 2001 Leonids burning up in the atmosphere as it crossed the constellation of Orion. This year there will be a this waning crescent Moon so it will mean that the sky will be dark so allowing faint trails to be seen. It is expected that, in general, only 12 to 15 meteors are likely to be seen per hour, but they do tend to be bright so it is worth getting up to view them. However there is a chance that for around 30 minutes at ~4:45 UT on the morning of the 19th November there will be a short outburst with perhaps one or two meteors visible per minute! Thus it could well be worth getting up that morning in the hope of seeing them. The dust particles that are swept up by the Earth are released as Comet Temple-Tuttle rounds the Sun every 33 years. It was last closest to the Sun in 1998 and we had some superb displays in the years that followed. The peak in activity on the morning of the 19th is when the Earth will cross a stream of particles ejected as the comet passed the Sun in 1932. The Earth last crossed this stream in 1969 when a rate of 200 meteors per hour was observed for 30 minutes. You might just be lucky!

Find the Andromeda Galaxy and observe Algol wink!

October25th
Early Evenings in November
Image: Stellarium/IM

The autumn is a good time to find the Andromeda galaxy. It is near the top of the chart just to the right of centre. Start at the top left star (Alpheratz) of the square of Pegasus, move round two bright stars to the left and up a bit to reach Mirach. At this point turn sharp right, move up one star and then the same distance again. A fainter star is passed and then you should see a fuzzy glow - that is the Nucleus of the Andromeda Galaxy. 10x50 binoculars on a really dark transparent night will show the disk extending out from the nucleus.

To the left of the tiny constellation Triangulum is the Star Algol in Perseus.

It is an eclipsing binary and every 2.87 days its brightness drops by more than a magnitude and then rises again. In November this year you can watch this happen over a period of hours around 00:07 UT on the 9th and 20:56 UT on the 11th.

The Planets

 A montage of the Solar System
A montage of the Solar System. JPL / Nasa

Jupiter

Jupiter
A Cassini image of Jupiter . Nasa

Jupiter lying in the constellation Libra, is passing behind the Sun during the early part of November but may just be visible at the very end of the month when it rises 30 minutes before the Sun and will be 5 degrees below and to the left of Mars. To be honest, its best left until December and January when it rise earlier - but it will be a morning object for several months yet.

Saturn

Saturn
The planet Saturn. Cassini - Nasa

Saturn is in the constellation Leo and about 6 degrees up and to the right of its brightest star Regulus at the start of November. It closes to around 5 degrees during the month. It rises in the east north-east in late evening and might well be best seen at about 6 am, before sun rise, when it is in the south and at its highets elevation. Its magnitude is ~ +0.6 and its globe subtends an angle of ~18 arc seconds. The rings are closing and are now about 15 degrees from edge-on, so Saturn will shine less brightly than during the previous eight years when the rings have been more open. Saturn is still a beautiful sight in a small telescope. A 4 to 6 inch telescope will also easily show Saturn's largest moon Titan, and an 8 inch three or four more.

The image was taken as the Cassini spacecraft neared Saturn at the start of its exploration of the planet and its moons - particularly Titan.

Mercury

Mercury.
Mariner 10 composite image of Mercury. Nasa

Mercury pases in front of the Sun on November 9th - a transit is visible around the Pacific Ocean but, sadly, not in Europe. It will be the last transit of Mercury until 2016. By November 16th it may be picked out with binoculars just before dawn and just 9 days later, on the 25th, reaches "western elongation" - its greatest angular seperation form the Sun. It will have a magnitude of ~ -0.7 and, given a low eastern horizon, should be fairly easy to spot in the hour before dawn.

Note that the blank region in the image above is simply because this part of Mercury's surface has not yet been imaged in detail.

Mars

Mars showing Syrtis major.
A Hubble Space Telescope image of Mars.
Jim Bell et al. AURA / STScI / Nasa

Mars passed behind the Sun on October 23rd and will reappear in the pre-dawn sky at the very end of November about 45 minutes before sunrise. It will be at magnitude +1.7, but its disk will be just 4 arc seconds across so no details will be seen on the salmon pink surface

Venus

Venus
Venus showing some cloud structure

Venus passed behind the Sun on October 27th so is barely visible this month. It might just be spotted with binoculars just after sunset at the very end of November, but its best to wait until December!

Radar Image of Venus
Radar image showing surface features

Find more planetary images and details about the Solar System: The Solar System

The Stars

The Evening November Sky

November Sky
The November Sky in the south - early evening

This map shows the constellations seen towards the south in early evening. To the south in early evening moving over to the west as the night progresses is the beautiful region of the Milky Way containing both Cygnus and Lyra. Below is Aquilla. The three bright stars Deneb (in Cygnus), Vega (in Lyra) and Altair (in Aquila) make up the "Summer Triangle". East of Cygnus is the great square of Pegasus - adjacent to Andromeda in which lies M31, the Andromeda Nebula. To the north lies "w" shaped Cassiopeia and Perseus. The constellation Taurus, with its two lovely clusters, the Hyades and Pleiades is rising in the east during the late evening.

The constellations Lyra and Cygnus

Cygnus and Lyra
Lyra and Cygnus

This month the constellations Lyra and Cygnus are seen almost overhead as darkness falls with their bright stars Vega, in Lyra, and Deneb, in Cygnus, making up the "summer triangle" of bright stars with Altair in the constellation Aquila below. (see sky chart above)

Lyra

Lyra is dominated by its brightest star Vega, the fifth brightest star in the sky. It is a blue-white star having a magnitude of 0.03, and lies 26 light years away. It weighs three times more than the Sun and is about 50 times brighter. It is thus burning up its nuclear fuel at a greater rate than the Sun and so will shine for a correspondingly shorter time. Vega is much younger than the Sun, perhaps only a few hundred million years old, and is surrounded by a cold,dark disc of dust in which an embryonic solar system is being formed!

There is a lovely double star called Epsilon Lyrae up and to the left of Vega. A pair of binoculars will show them up easily - you might even see them both with your unaided eye. In fact a telescope, provided the atmosphere is calm, shows that each of the two stars that you can see is a double star as well so it is called the double double!

The Double Double
Epsilon Lyra - The Double Double

Between Beta and Gamma Lyra lies a beautiful object called the Ring Nebula. It is the 57th object in the Messier Catalogue and so is also called M57. Such objects are called planetary nebulae as in a telescope they show a disc, rather like a planet. But in fact they are the remnants of stars, similar to our Sun, that have come to the end of their life and have blown off a shell of dust and gas around them. The Ring Nebula looks like a greenish smoke ring in a small telescope, but is not as impressive as it is shown in photographs in which you can also see the faint central "white dwarf" star which is the core of the original star which has collapsed down to about the size of the Earth. Still very hot this shines with a blue-white colour, but is cooling down and will eventually become dark and invisible - a "black dwarf"! Do click on the image below to see the large version - its wonderful!

M57 - The Ring Nebula
M57 - the Ring Nebula
Image: Hubble Space telescope

M56 is an 8th magnitude Globular Cluster visible in binoculars roughly half way between Alberio (the head of the Swan) and Gamma Lyrae. It is 33,000 light years away and has a diameter of about 60 light years. It was first seen by Charles Messier in 1779 and became the 56th entry into his catalogue.

M56 - Globular Cluster
M56 - Globular Cluster

Cygnus

Cygnus, the Swan, is sometimes called the "Northern Cross" as it has a distinctive cross shape, but we normally think of it as a flying Swan. Deneb,the arabic word for "tail", is a 1.3 magnitude star which marks the tail of the swan. It is nearly 2000 light years away and appears so bright only because it gives out around 80,000 times as much light as our Sun. In fact if Deneb where as close as the brightest star in the northern sky, Sirius, it would appear as brilliant as the half moon and the sky would never be really dark when it was above the horizon!

The star, Albireo, which marks the head of the Swan is much fainter, but a beautiful sight in a small telescope. This shows that Albireo is made of two stars, amber and blue-green, which provide a wonderful colour contrast. With magnitudes 3.1 and 5.1 they are regarded as the most beautiful double star that can be seen in the sky.

Alberio
Alberio: Diagram showing the colours and relative brightnesses

Cygnus lies along the line of the Milky Way, the disk of our own Galaxy, and provides a wealth of stars and clusters to observe. Just to the left of the line joining Deneb and Sadr, the star at the centre of the outstretched wings, you may, under very clear dark skys, see a region which is darker than the surroundings. This is called the Cygnus Rift and is caused by the obscuration of light from distant stars by a lane of dust in our local spiral arm. the dust comes from elements such as carbon which have been built up in stars and ejected into space in explosions that give rise to objects such as the planetary nebula M57 described above.

There is a beautiful region of nebulosity up and to the left of Deneb which is visible with binoculars in a very dark and clear sky. Photographs show an outline that looks like North America - hence its name the North America Nebula. Just to its right is a less bright region that looks like a Pelican, with a long beak and dark eye, so not surprisingly this is called the Pelican Nebula. The photograph below shows them well.

The North American Nebula
The North American Nebula

Brocchi's Cluster An easy object to spot with binoculars in Gygnus is "Brocchi's Cluster", often called "The Coathanger",although it appears upside down in the sky! Follow down the neck of the swan to the star Alberio, then sweep down and to its lower left. You should easily spot it against the dark dust lane behind.

The Coathanger
Brocchi's Cluster - The Coathanger

The constellations Pegasus and Andromeda

Pegasus and Andromeda
Pegasus and Andromeda

Pegasus

The Square of Pegasus is in the south during the evening and forms the body of the winged horse. The square is marked by 4 stars of 2nd and 3rd magnitude, with the top left hand one actually forming part of the constellation Andromeda. The sides of the square are almost 15 degrees across, about the width of a clentched fist, but it contains few stars visibe to the naked eye. If you can see 5 then you know that the sky is both dark and transparent! Three stars drop down to the right of the bottom right hand corner of the square marked by Alpha Pegasi, Markab. A brighter star Epsilon Pegasi is then a little up to the right, at 2nd magnitude the brightest star in this part of the sky. A little further up and to the right is the Globular Cluster M15. It is just too faint to be seen with the naked eye, but binoculars show it clearly as a fuzzy patch of light just to the right of a 6th magnitude star.

Andromeda

The stars of Andromeda arc up and to the left of the top left star of the square, Sirra or Alpha Andromedae. The most dramatic object in this constellation is M31, the Andromeda Nebula. It is a great spiral galaxy, similar to, but somewhat larger than, our galaxy and lies about 2.5 million light years from us. It can be seen with the naked eye as a faint elliptical glow as long as the sky is reasonably clear and dark. Move up and to the left two stars from Sirra, these are Pi amd Mu Andromedae. Then move your view through a rightangle to the right of Mu by about one field of view of a pair of binoculars and you should be able to see it easily. M31 contains about twice as many stars as our own galaxy, the Milky Way, and together they are the two largest members of our own Local Group of about 3 dozen galaxies.

M 31 - The Andromeda Nebula
M31 - The Andromeda Nebula

M33 in Triangulum

If, using something like 8 by 40 binoculars, you have seen M31 as described above, it might well be worth searching for M33 in Triangulum. Triangulum is

the small faint constellation just below Andromeda. Start on M31, drop down to Mu Andromedae and keep on going in the same direction by the same distance as you have moved from M31 to Mu Andromedae. Under excellent seeing conditions (ie., very dark and clear skies) you should be able to see what looks like a little piece of tissue paper stuck on the sky or a faint cloud. It appears to have uniform brightness and shows no structure. The shape is irregular in outline - by no means oval in shape and covers an area about twice the size of the Moon. It is said that it is just visible to the unaided eye, so it the most distant object in the Universe that the eye can see. The distance is now thought to be 3.0 Million light years - just greater than that of M31.

M33
M33 in triangulum - David Malin

The constellation Taurus

Taurus
Taurus

Taurus is one of the most beautiful constellations and you can almost imagine the Bull charging down to the left towards Orion. His face is delineated by the "V" shaped cluster of stars called the Hyades, his eye is the red giant star Aldebaran and the tips of his horns are shown by the stars beta and zeta Tauri. Although alpha Tauri, Aldebaran, appears to lie amongst the stars of the Hyades cluster it is, in fact, less than half their distance lying 68 light years away from us. It is around 40 times the diameter of our Sun and 100 times as bright.

The Hyades and Pleiades
The Hyiades and Pleiades. Copyright: Alson Wong.

More beautiful images by Alson Wong : Astrophotography by Alson Wong

To the upper right of Taurus lies the open cluster, M45, the Pleiades. Often called the Seven Sisters, it is one of the brightest and closest open clusters. The Pleiades cluster lies at a distance of 400 light years and contains over 3000 stars. The cluster, which is about 13 light years across, is moving towards the star Betelgeuse in Orion. Surrounding the brightest stars are seen blue reflection nebulae caused by reflected light from many small carbon grains. These relfection nebulae look blue as the dust grains scatter blue light more efficiently than red. The grains form part of a molecular cloud through which the cluster is currently passing. (Or, to be more precise, did 400 years ago!)

The Crab Nebula
VLT image of the Crab Nebula

Close to the tip of the left hand horn lies the Crab Nebula, also called M1 as it is the first entry of Charles Messier's catalogue of nebulous objects. Lying 6500 light years from the Sun, it is the remains of a giant star that was seen to explode as a supernova in the year 1056. It may just be glimpsed with binoculars on a very clear dark night and a telescope will show it as a misty blur of light.

The Crab Nebula
Lord Rosse's drawing of M1

Its name "The Crab Nebula" was given to it by the Third Earl of Rosse who observed it with the 72 inch reflector at Birr Castle in County Offaly in central Ireland. As shown in the drawing above, it appeared to him rather lile a spider crab. The 72 inch was the world's largest telelescope for many years. At the heart of the Crab Nebula is a neutron star, the result of the collapse of the original star's core. Although only around 20 km in diameter it weighs more than our Sun and is spinning 30 times a second. Its rotating magnetic field generate beams of light and radio waves which sweep across the sky. As a result, a radio telescope will pick up very regular pulses of radiation and the object is thus also known a Pulsar. Its pulses are monitored each day at Jodrell Bank with a 13m radio telescope.
