ALMA (personal image collection May-Sep 2010)

Photos by Diah Gunawan (DSG), Richard Hills (RH), Robert Laing (RAL), Alison Peck (AP). Please do not reproduce. Please see the ESO Image Archive for official images.
click to enlarge ALMAinChajnantur.jpg
original - 1224 kB

ALMA on 2010-09-05 - plenty of room to expand! DSG
click to enlarge
original - 1128 kB

The Atacama Pathfinder EXperiment operating for science observations. DSG
click to enlarge
original - 5107 kB

Melco antenna on the left, Vertex on the right. DSG
click to enlarge
original - 561 kB

Inside a Vertex antenna cabin DSG
click to enlarge
original - 589 kB

Receiver cartridge assembly provided byt the Rutherford Appleton Laboratory, UK. The receivers, cryostats and so on are interchangeable between antennas. DSG
click to enlarge
original - 3862 kB

One of the Melco antennas provided by the National Observatory of Japan. DSG
click to enlarge
original - 4788 kB

One of the Vertex antennas provided by the North American ALMA partners. DSG
click to enlarge
original - 5214 kB

These pads will eventually be occupied by 7-m antennas but the 12-m fit meanwhile... just! DSG
click to enlarge
original - 4874 kB

Six Vertex antennas and one Melco (right) at the Chajnantur Array Operations Site at 5000 m. DSG
click to enlarge
original - 541 kB

One of the AEM antennas provided by the European Southern Observatory. RH
click to enlarge
original - 46 kB

The antenna dishes are delivered in two halves to the Operation Support Facility at 2900 m. DSG
click to enlarge
original - 579 kB

From left to right: AEM antennas (some awaiting assembly), Melco antennas including a 7-m, the Vertex hangar and antennas. DSG
click to enlarge
original - 4967 kB

There are two transporters called Lore and Otto, here seen manouvering on the steep track to the AOS. DSG
click to enlarge
original - 1563 kB

Fortunately we had just pulled off the road before Otto appeared... DSG
click to enlarge
original - 614 kB

"She'll be coming round the mountain when she comes..." DSG
click to enlarge
original - 178 kB

Fortunately very rare snow. AP
click to enlarge
original - 6018 kB

The giant cacti grow in a very narrow altitude range. DSG
